DC-1100/1300/1500

home > products > High Speed Bridge Type > DC-1100/1300/1500
  • SPECIFICATIONS Unit
    Travel X-Axis travel mm
    Y-Axis travel mm
    Z-Axis travel mm
    Linear guide
    way    		 X-Axis
    Y-Axis
    Z-Axis
    Ball screw X-Axis
    Y-Axis
    Z-Axis
    Table Area mm
    Max. Table load kgs
    T-slot dia. mm
    Spindle Spindle taper
    Spindle speed and driving method RPM
    Spindle speed and driving method* OP RPM
    Distance Spindle nose to table surface mm
    Spindle center nose to column mm
    Tool Tool capacity
    Max. Length of tool mm
    Max. Dia of tool mm
    Max. Weight of tool kgs
    Tool change time sec
    Feeding Rapid feed speed m/min
    Controller Mitsubishi controller (10.4")
    Fanuc controller (8.4")
    Motor Spindle motor HP
    Feed motor Mitsubishi controller (10.4") KW
    Fanuc controller (8.4") KW
    Comptessed air supply kg/cm2
    Machine size( Length x Width x Height ) cm
    Net weight kgs
    Suitable container
    DC-1100 DC-1300 DC-1500
    1,100 1,300 1,500
    1,100
    750
    RGW45
    RGW55
    RGW45
    R50 x P12
    R50 x P12
    R50 x P12
    1,200 x 1,150 1,400 x 1,150 1,600 x 1,150
    2,000
    CD 125 x 18 x 9T
    BBT40
    12,000 Direct type
    15,000 Direct type or 20,000 / 24,000 Built-in type
    100-850
    456
    24
    300
    135
    8
    1.31 (60HZ)
    X:36, Y:36, Z:24
    M80
    0i-MF α8
    15
    X:3.5, Y:3.5, Z:3.5
    X:4.0, Y:4.0, Z:4.0
    6
    330*340*335 330*360*335 330*380*335
    12,000 12,400 13,750
    20'FR
    ※Specification is subject to change without prior notice.
  • STANDARD ACCESSORIES
    1. Alarm light
    2. Arm type ATC
    3. Remote MPG
    4. Full enclosure
    5. Rigid tapping
    6. Spindle oil cooler
    7. RS232 Interface
    8. Heat exchanger
    9. Coolant flushing system
    10. A.I.Contour Control
    11. Auto lubricating system
    12. Auto power off system
    13. Metal telescopic cover
    14. Double screw type chip conveyor (with tank)
    15. Level adjusting bolts and pads
    16. Spindle auto flush / air blast device
    17. Handle flush and air blast device
    18. Tool box with tool kits
    OPTIONAL ACCESSORIES
    1. Air-conditioner
    2. Coolant ring
    3. Tool setter
    4. Oil-water separator
    5. Rotary table
    6. C.T.S (coolant thrugh spindle)
    7. Boat type chip conveyor (with tank)
    8. Spin window
